Blobber
Details on the blobber, the actual storage provider for user data
The blobber is the most important provider when it comes to hosting users' data. It provides actual storage space to host this data on its file system and gets rewards in return. Users can host their own blobber on premises or on our dedicated servers through the Chimney Webapp.
Core responsibilities of the Blobber
Host users' data on its file system
Maintain the correctness and availability of the users data on-demand.
Provide a highly-available interface (currently an HTTP API) for the users to access or modify their data.
Answer the challenges so it can get rewards
Logical component of the Blobber's Process
The Sharder Process consists of multiple workers (technically, lightweight execution threads or goroutines in the Go literature). Following are the most important workers running the miner operations
Allocation Sync Worker
An Allocation is like a contract between the user and Züs network about some data the user need to host on the Network. One of the terms that the user choose during creating the allocation is the blobbers that will host their data based on this allocation. Since this coordination occurs between the user and the blockchain network (miners and sharders to simplify), the blobber knows nothing about the allocation unless it requests this data from the network using one of the endpoints of the Sharder API. This worker periodically polls this endpoint for updates and persists the information of the new allocations
Challenge Workers
Challenges is how the blobbers get time-based rewards for storage. In simple words, a challenge is a validation inquiry of a portion of the data that should be hosted by some blobber i.e. trying to check if the blobber is really hosting this portion of data or not. They're generated by the network using a special type of transactions called Built-in Transactions that are autogenerated by the network on each block generation. A challenge is generated:
For a specific Blobber
Asking about a specific Allocation
And a specific Block of data in this allocation
Similar to Allocations, Challenges are generated and kept in the blockchain network and the blobber knows nothing about it until it requests this data from the network also using one of the endpoints of the Sharder API. It then answers those challenges and send its response back to the network, which in turn validates the answer and either rewards or penalizes the blobber, based on the answer. These tasks: polling the network for new challenges, answering the challenges and sending the answers to the network, are the responsibility of these workers. More about challenges are to come in the Challenges page.
Read/Write Markers Workers
Read Markers are chique-like structures sent by the blobbers to the network in order to get fees of read operations from the client's wallet, same for Write Markers for write operations. Both will be discussed in more details in the Read/Write Markers page. Those workers handle the markers flow until the marker is fulfilled and redeemed.
Health Check Worker
A worker responsible for the heartbeats of the blobber which are signs of the blobber liveness. It works by generating a health check transaction periodically and communicate it with the network.
Update Settings Worker
The owner of the blobber - the user who created the blobber on Chimney - can update the settings of the blobber. However, they will not be communicating with the blobber directly, this settings update operation is submitted as a transaction to the network, thus unseen by the blobber unless it requests this data from the network using the Sharder API. So the responsibility of this worker is to sync blobber settings with the network periodically.
The Blobber HTTP API
The blobber exposes an HTTP API as an interface of the file operations the users' need to execute on their data. It's discussed in more details in the Blobber API page.
Blobber Settings
These are the settings that the owners can change about their blobbers.
Those settings can only be changed by the owner's wallet.
Capacity (Bytes)
This is the maximum capacity that the blobber offers to use for hosting users' data.
Read Price (SAS/GB/Time Unit)
SAS is the smallest countable unit of the ZCN token. One ZCN is 10^10 SAS
This is how much the user pays for read operations against this blobber, it's calculates per GB per Time Unit where Time Unit is one of the storage configuration elements mentioned in Smart Contracts Configuration page.
Write Price (SAS/GB/Time Unit)
This is how much the user pays for write operations against this blobber, it's calculates per GB per Time Unit where Time Unit is one of the storage configuration elements mentioned in Smart Contracts Configuration page.
Max Offer Duration (duration string e.g. 700h - 3m - ..)
This is how long the blobber can keep its prices without change. After this duration elapses, the blobber's prices change and all allocations need to be updated.
Min Stake (SAS)
This is the least amount the blobber can be staked with by a single client. Staking is discussed in more details in the Tokenomics page.
Max Stake (SAS)
This is the largest amount the blobber can be staked by a single client. Staking is discussed in more details in the Tokenomics page.
Max Number of Delegates (no unit)
This is the maximum number of clients that can be delegates to the blobber by staking. Delegation is discussed in more details in the Tokenomics page.
Service Charge (Decimal, 0 to 1)
This is the ratio the blobber receives from each storage reward it earns before the rest is distributing over its delegates.
URL (text)
The URL of the homepage of the blobber.
Not Available (boolean)
Whether the blobber is available for hosting users' data or not.
